CCVH2150X - Eaton Cutler Hammer 150A 2-Pole 120/240V Type CCV Tenant Main Circuit Breaker NEMA 1/3R

CCVH2150X

CCVH2150X is a Type CCV tenant main circuit breaker designed for reliable power distribution in commercial and residential applications. This breaker features a two-pole configuration, 150A amperage, and a 25kA interrupt rating, suitable for 120/240V systems. It is specifically engineered for use with Type ECC unit enclosures and includes load side lugs for easy connection. This Eaton Cutler Hammer breaker is built for durability and safety, meeting UL 489 certification standards. The bolt-on mounting design ensures secure installation, while the wide wire size compatibility (2/0 AWG to 300 kcmil Cu/Al) provides flexibility for various wiring needs. The breaker is ideal for tenant main applications where robust protection and compliance are essential.

• Part Number: CCVH2150X
• Manufacturer: Eaton Cutler Hammer
• Amperage: 150A
• Voltage: 120/240V
• Poles: 2-Pole
• Interrupt Rating: 25kAIC
• Series/Frame: Type CCV
• Mounting Type: Bolt-On
• Terminal Type: Load Side Lugs
• Wire Size: 2/0 AWG - 300 kcmil Cu/Al
• Enclosure Compatibility: Type ECC
• Certifications: UL 489

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: CCVH2150X
• Manufacturer : Cutler Hammer
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Tenant Main
• Type : CCVH
• Voltage : 240
• Amperage : 150
• Phase : 1
• Poles : 2
• AIC rating : 25kA@240V
• Connection : Bolt-On
• Functions : LI - Long-Time and Instantaneous
• Protection : Thermal Magnetic

Product Data

• UPC : 786685368498
• Country of Origin : Dominican Republic
• Dimensions : 7.7 in x 5.4 in x 4.5 in (Length/Depth x Height x Width)
• Weight : 2.9
• Certification : UL 489
