Product Info
- Manufacturer:Cutler Hammer
- Sub-Category:Molded Case
Description
CCH3175
CCH3175 is a Cutler Hammer 3 pole molded case circuit breaker designed for reliable circuit protection in commercial and industrial applications.
This thermal magnetic circuit breaker features a 175A amperage rating, 240V maximum voltage, and a high magnetic trip unit for enhanced protection. It is part of the CCH series, offers feed-thru mounting, and is UL 489 listed for safety and compliance.
-
Key Specifications
- Part Number: CCH3175
- Manufacturer: Cutler Hammer (Eaton)
- Amperage: 175A
- Voltage: 240VAC
- Poles: 3
- Mounting Type: Feed-Thru
- Interrupt Rating: 25kA @ 240V
- Series/Frame: CCH
- Trip Unit: Thermal Magnetic, High Magnetic
- Certifications: UL 489
- Terminal: Aluminum/Copper Line
At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.
Specifications
- Part Number: CCH3175
- Manufacturer : Cutler Hammer
- Brand : Cutler Hammer
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : CCH Series
- Type : CCH
- Voltage : 240
- Amperage : 175
- Phase : 3
- Poles : 3
- AIC rating : 25kA@240V
- Connection : Feed-Thru
- Functions : Long Time and Instantaneous Trip
- Temp Rating : -13–158 °F (-25–70 °C)
- Protection : Thermal Magnetic
Product Data
- UPC : 782113338590
- GTIN : 00782113338590
- Country of Origin : Dominican Republic
- Dimensions : 7.7 in x 5.2 in x 5.7 in (Length/Depth x Height x Width)
- Weight : 4.2
- Certification : UL 489
- Wire Size : #2/0 AWG to 300KCmil CU/AL
