CC3225 - Cutler Hammer 225A 240V 3-Pole Molded Case Circuit Breaker Type CC 10kA Interrupt

CC3225

CC3225 is a Cutler Hammer molded case circuit breaker designed for reliable electrical protection in commercial and industrial applications.This Type CC circuit breaker features a 225 ampere rating, 240 volt voltage rating, and three poles. It offers a 10 kiloampere interrupt rating at 240 VAC and is suitable for use in Type ECC unit enclosures. The breaker uses a thermal-magnetic trip unit and supports wire sizes from #2/0 AWG to 300 kcmil copper or aluminum conductors. It is UL 489 certified for safety and performance.

• Amperage: 225 A
• Voltage: 240 V
• Poles: 3
• Interrupt Rating: 10 kAIC
• Type: CC Molded Case Circuit Breaker
• Trip Unit: Thermal-Magnetic
• Mounting: Line/Load Lug Connection
• Wire Size Range: #2/0 AWG - 300 kcmil Cu/Al
• Frame: Type CC
• Certifications: UL 489
• Compatible with Type ECC Unit Enclosures

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: CC3225
• Manufacturer : Cutler Hammer
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : CC Series
• Type : CC
• Voltage : 240
• Amperage : 225
• Phase : 3
• Poles : 3
• AIC rating : 10kA@240V
• Connection : Feed-Thru
• Functions : LI - Long-Time and Instantaneous
• Protection : Thermal Magnetic

Product Data

• UPC : 782113266657
• GTIN : 00782113266657
• Country of Origin : Dominican Republic
• Dimensions : 7.75 in x 5.25 in x 5.75 in (Length/Depth x Height x Width)
• Weight : 4.2
• Certification : UL 489
• Wire Size : 2/0 AWG-300 KCMIL (Aluminum/Copper)
