CC3175N - Cutler Hammer 175A 120/240V 3-Pole Type CC Molded Case Circuit Breaker 10kA Interrupt

CC3175N

CC3175N is a Cutler Hammer Type CC molded case circuit breaker rated for 175 amps and 120/240 volts with 3 poles and a 10 kA interrupt rating.This circuit breaker features a thermal/magnetic trip unit and is designed for plug-in mounting in Type ECC unit enclosures. It supports wire sizes from #2/0 to 300 kcmil copper or aluminum conductors and is UL 489 listed and CSA certified. The breaker measures 7.7 inches deep, 4.5 inches wide, and 5.4 inches high, with a limited lifetime warranty for residential use and one year for commercial applications.

Key Specifications
• Amperage Rating: 175 A
• Voltage Rating: 120/240 V AC
• Number of Poles: 3
• Interrupt Rating: 10 kAIC
• Mounting Type: Plug-In
• Trip Unit: Thermal/Magnetic
• Wire Size Range: #2/0 to 300 kcmil Cu/Al
• Dimensions: 7.7 x 4.5 x 5.4 inches
• Certifications: UL 489 Listed, CSA Certified
• Series/Frame: Type CC
At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.


Specifications

• Part Number: CC3175N
• Manufacturer : Cutler Hammer
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : CC Series
• Type : CC
• Voltage : 240
• Amperage : 175
• Phase : 3
• Poles : 3
• AIC rating : 10kA@240V
• Connection : Feed-Thru
• Functions : LI - Long-Time and Instantaneous
• Protection : Thermal Magnetic



Product Data

• UPC : 782114652077
• GTIN : 00782114652077
• Country of Origin : Dominican Republic
• Dimensions : 7.7 in x 5.4 in x 4.5 in (Length/Depth x Height x Width)
• Weight : 3
• Certification : UL 489
