CC3100 - Cutler Hammer 100A 240V 3-Pole Molded Case Circuit Breaker, 10kA Interrupt Rating, Bolt-On Mount

CC3100

CC3100 is a 3-pole, 100 amp, 240 volt molded case circuit breaker from Cutler Hammer designed for reliable circuit protection.This bolt-on mounted breaker features a thermal-magnetic trip unit with a 10 kiloamp interrupt rating (kAIC) at 240 volts. It supports copper and aluminum wire sizes from 4 AWG to 4/0 AWG and is UL 489 listed and CSA certified. The CC3100 is part of the CC series and is suitable for use in Type ECC unit enclosures.

Key Specifications
• Amperage: 100 A
• Voltage Rating: 240 V
• Number of Poles: 3
• Mounting Type: Bolt-On
• Interrupt Rating: 10 kAIC @ 240 V
• Wire Size: #4 to 4/0 AWG Cu/Al
• Series/Frame: CC
• Trip Unit: Thermal-Magnetic
• Certifications: UL 489 Listed, CSA Certified
• Phase: 3
At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.


Specifications

• Part Number: CC3100
• Manufacturer : Cutler Hammer
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : CC Series
• Type : CC
• Voltage : 240
• Amperage : 100
• Phase : 3
• Poles : 3
• AIC rating : 10kA@240V
• Connection : Feed-Thru
• Functions : LI - Long-Time and Instantaneous
• Protection : Thermal Magnetic



Product Data

• UPC : 782113386553
• GTIN : 00782113386553
• Country of Origin : Dominican Republic
• Dimensions : 8 in x 5.5 in x 4.5 in (Length/Depth x Height x Width)
• Weight : 3
• Certification : UL 489
• Wire Size : 4-4/0 AWG (Aluminum/Copper)
