CC3150SR01 - Cutler Hammer 150A 240V 3-Pole Type CC Molded Case Circuit Breaker with 120V Shunt Trip

CC3150SR01

CC3150SR01 is a Cutler Hammer Type CC molded case circuit breaker rated for 150 amps and 240 volts with 3 poles and a 120V shunt trip feature.CC3150SR01 provides reliable thermal magnetic trip protection in a compact Type CC frame, suitable for use in various electrical distribution applications. It supports copper and aluminum conductors from #4 AWG to 4/0 AWG at 60°C or 75°C and has a 10 kA interrupting rating at 240VAC.

• Type CC molded case circuit breaker
• 3 poles
• 150 ampere rating
• 240 volts AC voltage rating
• 120V shunt trip
• Thermal magnetic trip unit
• 10 kA interrupting rating (AIC)
• Compatible with #4 AWG to 4/0 AWG Cu/Al conductors at 60°C or 75°C
• Cutler Hammer / Eaton brand

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Additional Information

complete with 120VAC shunt trip

Specifications

• Part Number: CC3150SR01
• Manufacturer : Cutler Hammer
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : CC Series
• Type : CC
• Voltage : 240
• Amperage : 150
• Phase : 3
• Poles : 3
• AIC rating : 10kA@240V
• Connection : Feed-Thru
• Functions : Long Time and Instantaneous Trip
• Temp Rating : -13–158 °F (-25–70 °C)
• Protection : Thermal Magnetic

Product Data

• UPC : 782113420479
• GTIN : 00782113420479
• Country of Origin : Dominican Republic
• Dimensions : 5 in x 1 in x 3 in (Length/Depth x Height x Width)
• Weight : 0.5
• Certification : UL 489
• Wire Size : 4 to 4/0 AWG, Cu/Al
