C25FNF360H - Cutler Hammer 60A 600V 3-Pole Definite Purpose Contactor

C25FNF360H

C25FNF360H is an Eaton Cutler Hammer definite purpose contactor rated for 60 amperes at 600VAC with a 277VAC 60Hz coil, designed for three-pole motor control applications. This non-reversing contactor features a C25 frame size and open enclosure with metal mounting plate, making it suitable for HVAC and refrigeration equipment control. The unit is equipped with box lugs and quick connect terminals for flexible installation options.

• Amperage Rating: 60A
• Voltage Rating: 600VAC
• Coil Voltage: 277VAC, 60Hz
• Number of Poles: Three-pole
• Frame Size: C25
• Enclosure Type: Open with metal mounting plate
• Reversing Capability: Non-reversing
• Terminal Type: Box lugs and quick connect terminals
• Resistive Load Rating: 75A per pole
• Certifications: UL Recognized, CSA Certified, RoHS Compliant
• Product Dimensions: 3.75 in H x 4.1 in W x 3.97 in D
• Weight: 2.8 lb

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Additional Information

This Definite Purpose Contactor includes a 277 VAC coil.

Specifications

• Part Number: C25FNF360H
• Manufacturer : Cutler Hammer
• Brand : Cutler Hammer
• Category : Motor Control
• Item Subcategory : Contactor
• Family : C25 Series
• Type : C25
• Voltage : 600
• Amperage : 60
• Phase : 3
• Poles : 3
• Temp Rating : -13–158 °F (-25–70 °C)
• Configuration : Non-Reversing
• Coil Voltage Maximum : 277
• Coil Voltage Minimum : 277
• Frequency : 60 Hz

Product Data

• UPC : 782113627151
• GTIN : 00782113627151
• Country of Origin : Dominican Republic
• Dimensions : 3.97 in x 3.75 in x 2.63 in (Length/Depth x Height x Width)
• Weight : 2.8 lb
• Temp Rating : -13–158 °F (-25–70 °C)
• Certification : UL Recognized,CSA Certified,RoHS Compliant
