Product Info
- Manufacturer:Cutler Hammer
- Sub-Category:Contactor
Description
C25FNF260B
C25FNF260B is a Cutler Hammer definite purpose contactor designed for motor control applications with a 60 amp rating and 2 poles.
This C25 Series contactor operates at 208-240 VAC coil voltage with 50/60 Hz frequency. It features an open design with a metal mounting plate for easy installation. Rated for 60 amps continuous current, it supports up to 600 volts and is suitable for single-phase applications. The contactor includes box lug terminals for secure wiring connections.
- Amperage: 60A
- Voltage: 600V max
- Coil Voltage: 208-240 VAC
- Frequency: 50/60 Hz
- Poles: 2
- Frame Type: C25 Series
- Mounting: Open with metal mounting plate
- Application: Definite purpose contactor for motor control
At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.
Additional Information
This Definite Purpose Contactor includes a 208 VAC coil.
Specifications
- Part Number: C25FNF260B
- Manufacturer : Cutler Hammer
- Brand : Cutler Hammer
- Category : Motor Control
- Item Subcategory : Contactor
- Family : C25 Series
- Type : C25
- Voltage : 600
- Amperage : 60
- Phase : 1
- Poles : 2
- Configuration : Non-Reversing
- Coil Voltage Maximum : 240
- Coil Voltage Minimum : 208
- Frequency : 50 Hz
Product Data
- UPC : 782113476117
- GTIN : 00782113476117
- Country of Origin : Dominican Republic
- Dimensions : 3.97 in x 3.75 in x 2.63 in (Length/Depth x Height x Width)
- Weight : 2.55 lb
- Certification : CSA Certified,UL Recognized,RoHS Compliant
