Product Info
- Manufacturer:Cutler Hammer
- Sub-Category:Contactor
Description
C25FNF275C
C25FNF275C is a Cutler Hammer C25 Series definite purpose contactor rated for 75 amperes at 600 volts with a 2-pole configuration and 440-480 Vac coil. This motor control device is designed for reliable switching and protection in industrial applications requiring single-phase motor control up to 7.5 horsepower at 230 volts. The contactor features quick-connect terminals and is certified by UL and CSA for safety and performance standards.
- Amperage Rating: 75A
- Voltage: 600V
- Poles: 2
- Coil Voltage: 440-480 Vac, 50/60 Hz
- Series: C25
- Type: Non-reversing Definite Purpose Contactor
- Connection: Quick-connect
- Horsepower: Up to 7.5 HP at 230V
- Certifications: UL, CSA, IEC
Specifications
- Part Number: C25FNF275C
- Manufacturer : Cutler Hammer
- Brand : Cutler Hammer
- Category : Motor Control
- Item Subcategory : Contactor
- Family : C25 Series
- Type : C25
- Voltage : 600
- Amperage : 75
- Phase : 1
- Poles : 2
- Configuration : Non-Reversing
- Coil Voltage Maximum : 480
- Coil Voltage Minimum : 440
Product Data
- UPC : 782114623497
- GTIN : 00782114623497
- Country of Origin : Dominican Republic
- Dimensions : 3.97 in x 3.75 in x 2.63 in (Length/Depth x Height x Width)
- Weight : 2.66 lb
- Certification : CSA Certified,UL Recognized,RoHS Compliant
