Product Info
- Manufacturer:Cutler Hammer
- Sub-Category:Contactor
Description
C25DRE325A
C25DRE325A is a Cutler Hammer definite purpose contactor designed for reliable motor control applications. This contactor features a robust NEMA 1 enclosure and is suitable for use in a variety of industrial environments.Engineered for durability and performance, the C25DRE325A contactor supports a wide range of motor loads and is compatible with standard control circuits. It is a three-pole, non-reversing device with a 25A current rating and operates at 110-120VAC, 50/60 Hz. The unit is designed for easy mounting and integration into control panels.
- 25A Current Rating
- 110-120VAC Coil Voltage
- 3 Pole Configuration
- Non-Reversing Type
- NEMA Type 1 Enclosure
- 50/60 Hz Frequency
- Quick Series Frame
- UL and CSA Certified
- IEC Compliant
- DIN Rail Mounting Adapter Included
Additional Information
This Definite Purpose Contactor includes a 110 VAC coil.
Specifications
- Part Number: C25DRE325A
- Manufacturer : Cutler Hammer
- Brand : Cutler Hammer
- Category : Motor Control
- Item Subcategory : Contactor
- Family : C25 Series
- Type : C25
- Voltage : 600
- Amperage : 40A
- Phase : 3
- Poles : 3
- Horse Power : 10
- Configuration : Non-Reversing
- Coil Voltage Maximum : 120
- Coil Voltage Minimum : 110
- Frequency : 50 Hz
Product Data
- UPC : 782116896493
- GTIN : 00782116896493
- Country of Origin : United States
- Dimensions : 3.35 in x 3.75 in x 2.4 in (Length/Depth x Height x Width)
- Weight : 1.3 lb
- Certification : CSA Certified UL Recognized
