Product Info
- Manufacturer:Cutler Hammer
- Sub-Category:Contactor
Description
C25BNB230H
C25BNB230H is a Cutler Hammer definite purpose contactor designed for motor control applications with a 30 amp rating and 2 poles.This compact, two-pole contactor features a 277 VAC coil at 60 Hz and supports up to 600 VAC operational voltage. It is non-reversing and comes with an open enclosure with a metal mounting plate. The contactor includes binding head screw and quick connect terminals arranged side-by-side for easy wiring. Certified by UL and CSA, it is RoHS compliant and suitable for reliable motor control in industrial environments.
- Amperage Rating: 30A
- Voltage Rating: 600 VAC
- Coil Voltage: 277 VAC, 60 Hz
- Number of Poles: 2 (Two-pole)
- Type: Non-reversing
- Mounting: Open with metal mounting plate
- Frame Size: Compact (C25 series)
- Terminals: Binding head screw and quick connect (side-by-side)
- Interrupt Rating: Suitable for motor control loads
- Certifications: UL Recognized, CSA Certified, RoHS Compliant
Additional Information
This Definite Purpose Contactor includes a 277 VAC coil.
Specifications
- Part Number: C25BNB230H
- Manufacturer : Cutler Hammer
- Brand : Cutler Hammer
- Category : Motor Control
- Item Subcategory : Contactor
- Family : C25 Series
- Type : C25
- Voltage : 600
- Amperage : 30
- Phase : 1
- Poles : 2
- Configuration : Non-Reversing
- Coil Voltage Maximum : 277
- Coil Voltage Minimum : 277
- Frequency : 50 Hz
Product Data
- UPC : 786685116051
- GTIN : 00786685116051
- Country of Origin : China
- Dimensions : 2.32 in x 3.19 in x 1.97 in (Length/Depth x Height x Width)
- Weight : 0.7 lb
