C25BNB220B - Cutler Hammer C25 Series 2 Pole 20A 600V Definite Purpose Contactor, 208-240V Coil, DIN Rail/Panel/Surface Mount, UL/CSA/CE/IEC

C25BNB220B

C25BNB220B is a Cutler Hammer C25 Series 2-pole, 20A definite purpose contactor designed for reliable motor control in demanding environments.

This compact, non-reversing contactor features a 208-240V AC coil, 600V voltage rating, and is suitable for heating, air conditioning, refrigeration, and data processing applications. It offers quick connect and binding head screw terminals, an open metal mounting plate, and is engineered to limit dust and noise for enhanced durability and performance.

Key Specifications
• Amperage: 20A
• Voltage: 600VAC
• Poles: 2
• Mounting Type: DIN Rail, Panel, Surface
• Interrupt Rating: Not specified
• Series/Frame: C25
• Trip Unit: Not applicable
• Certifications: UL, CSA, CE, IEC, RoHS
• Coil Voltage: 208-240VAC, 50/60Hz
• Connection: Quick connect and binding head screw terminals
• Enclosure: Open with metal mounting plate
• Temperature Rating: -13 to 158°C

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Additional Information

This Definite Purpose Contactor includes a 208 VAC coil.

Specifications

• Part Number: C25BNB220B
• Manufacturer : Cutler Hammer
• Brand : Cutler Hammer
• Category : Motor Control
• Item Subcategory : Contactor
• Family : C25 Series
• Type : C25
• Voltage : 600
• Amperage : 20
• Phase : 1
• Poles : 2
• Temp Rating : -13–158 °F (-25–70 °C)
• Configuration : Non-Reversing
• Coil Voltage Maximum : 240
• Full Load Amps : Full Load Amps-Inductive 20A Full Load Amps-Resistive 30A
• Coil Voltage Minimum : 208
• Frequency : 50 Hz

Product Data

• UPC : 078668511595
• GTIN : 00786685115955
• Country of Origin : China
• Dimensions : 2.32 in x 3.19 in x 1.97 in (Length/Depth x Height x Width)
• Weight : 0.65 lb
• Temp Rating : -13–158 °F (-25–70 °C)
• Certification : CSA, RoHS, UL Listed
