C25BNB230B - Cutler Hammer C25 Series 2 Pole 30A 600V Contactor with 208-240V Coil

C25BNB230B

C25BNB230B is a Cutler Hammer C25 Series 2 pole 30A 600V contactor designed for motor control applications with a 208-240V coil.This compact, non-reversing contactor features quick connect and binding head screw terminals, open enclosure with metal mounting plate, and is suitable for both inductive and resistive loads. Ideal for use in HVAC, industrial, and commercial power control systems.

• Part Number: C25BNB230B
• Manufacturer: Cutler Hammer, Div of Eaton
• Series: C25
• Amperage Rating: 30A (Inductive), 40A (Resistive)
• Number of Poles: 2NO
• Coil Voltage: 208-240V AC, 50/60 Hz
• Mounting Type: Open with metal mounting plate
• Enclosure: Open
• Terminals: Binding head screw and quick connect (side-by-side)
• Interrupt Rating: Not specified
• Trip Unit: Not applicable
• Certifications: CSA, UL Recognized, RoHS Compliant

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Additional Information

This Definite Purpose Contactor includes a 110 VAC coil.

Specifications

• Part Number: C25BNB230B
• Manufacturer : Cutler Hammer
• Brand : Cutler Hammer
• Category : Motor Control
• Item Subcategory : Contactor
• Family : C25 Series
• Type : C25
• Voltage : 600
• Amperage : 30
• Phase : 1
• Poles : 2
• Temp Rating : -13–158 °F (-25–70 °C)
• Configuration : Non-Reversing
• Coil Voltage Maximum : 240
• Full Load Amps : Full Load Amps-Inductive 30A Full Load Amps-Resistive 40A
• Coil Voltage Minimum : 208
• Compatible Frames : DK,KDB,KD,HKD,KDC
• Frequency : 50 Hz

Product Data

• UPC : 786685116037
• GTIN : 00786685116037
• Country of Origin : China
• Dimensions : 2.32 in x 3.19 in x 1.97 in (Length/Depth x Height x Width)
• Weight : 0.6 lb
• Temp Rating : -13–158 °F (-25–70 °C)
• Certification : CSA, RoHS, UL Listed
