BRHH2100 - Cutler Hammer 100 Amp 2 Pole 120/240V Plug-On Circuit Breaker, 42 kAIC, BR Series, Thermal Magnetic Trip, UL Listed

BRHH2100

BRHH2100 is a Cutler Hammer 100 Amp, 2-pole, 120/240V plug-on circuit breaker designed for reliable protection in residential and light commercial applications.

This thermal magnetic circuit breaker features a 42 kAIC interrupting rating, common trip mechanism, and is compatible with #4-1/0 AWG copper or aluminum wire. It is UL listed and engineered for use in Type BR loadcenters, offering robust performance and easy installation.

Key Specifications
• Amperage: 100 A
• Voltage: 120/240 V AC
• Poles: 2
• Mounting Type: Plug-on
• Interrupt Rating: 42 kAIC @ 240V
• Series/Frame: BR Series, Type BR
• Trip Unit: Thermal magnetic, long-time and instantaneous trip
• Wire Size: #4-1/0 AWG Cu/Al
• Certifications: UL 490, Federal Specifications Classification W-C376
• Dimensions: 3" H x 2" W x 2.5" D
• Weight: 0.6 lb
• Main Circuit Breaker: BRH

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: BRHH2100
• Manufacturer : Cutler Hammer
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : BR Series
• Type : BRHH
• Voltage : 240
• Amperage : 100
• Phase : 1
• Poles : 2
• AIC rating : 42kA@240V
• Connection : Plug-In
• Functions : LI - Long-Time and Instantaneous Trip
• Temp Rating : -13–158 °F (-25–70 °C)
• Protection : Thermal Magnetic

Product Data

• UPC : 786676376952
• GTIN : 00786676376952
• Country of Origin : Dominican Republic
• Dimensions : 2.5 in x 3 in x 2 in (Length/Depth x Height x Width)
• Weight : 0.6
• Certification : UL 490,Federal Specifications Classification W-C376
• Wire Size : AWG 4 to AWG 1/0, Cu/Al
