BRCAF120CS - Cutler Hammer 20 Amp 1 Pole 120V AFCI Plug-In Molded Case Circuit Breaker, Type BR, 10kAIC, UL 1699

BRCAF120CS

BRCAF120CS is a Cutler Hammer (Eaton) single-pole, 20 Amp, 120V AFCI molded case circuit breaker designed for Type BR loadcenters.

This combination arc fault circuit interrupter (AFCI) breaker provides advanced protection by detecting both series and parallel arc faults, helping to prevent electrical fires. It features a plug-in mounting style for easy installation and is suitable for residential and light commercial applications where enhanced electrical safety is required.

Key Specifications
• Part Number: BRCAF120CS
• Manufacturer: Cutler Hammer (Eaton)
• Amperage: 20A
• Voltage: 120V
• Poles: 1
• Mounting Type: Plug-in
• Interrupt Rating: 10kAIC at 120V
• Series/Frame: Type BR
• Trip Unit: AFCI (Arc Fault Circuit Interrupter)
• Wire Size: #14-4 AWG Copper/Aluminum
• Certifications: UL 1699, Federal Specifications Classification W-C375
• Application: Residential and light commercial loadcenters

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: BRCAF120CS
• Manufacturer : Cutler Hammer
• Brand : Eaton
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : BR Series
• Type : BRCAF
• Voltage : 120
• Amperage : 20
• Phase : 1
• Poles : 1
• AIC rating : 10kA@120V
• Connection : Plug-In
• Functions : Long-Time and Instantaneous Trip
• Terminal Connection : Pigtail
• MCM Size : Min. Wire Size 14 AWG (Cu/Al) Max. Wire Size 4 AWG (Cu/Al)
• Breaker Type : BR
• Protection : Thermal Magnetic

Product Data

• UPC : 786685514376
• GTIN : 00786685514376
• Country of Origin : Dominican Republic
• Dimensions : 6 in x 1.25 in x 3.5 in (Length/Depth x Height x Width)
• Weight : 0.45
• Panel Type : Type BR Loadcenters
• Standards : UL 1699
• Wire Size : AWG 14 to AWG 4, Cu/Al
