BR270 - Eaton Cutler Hammer 70 Amp 120/240V 2-Pole Thermal Magnetic Circuit Breaker Plug-On BR Frame

BR270

BR270 is a 2-pole, 70 Amp, 120/240 Volt thermal magnetic circuit breaker from Eaton Cutler Hammer designed for Type BR load centers.This BR series breaker features a plug-on mounting type with a 10 kA interrupting rating at 240V. It includes long-time and instantaneous trip functions with common breaker trip for enhanced protection. The breaker supports wire sizes from AWG 8 to 1/0 Cu/Al and is UL 489 and CSA certified.

• Amperage: 70A
• Voltage: 120/240 VAC
• Poles: 2
• Mounting Type: Plug-On
• Interrupt Rating: 10 kAIC at 240V
• Series/Frame: BR
• Trip Unit: Thermal Magnetic with common breaker trip
• Wire Gauge: AWG 8 to 1/0 Cu/Al
• Certifications: UL 489, CSA
• Used with: Type BR Load Centers
• Connection Type: Plug-In
• Dimensions: 2.8" L x 1.9" W x 2.5" H

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: BR270
• Manufacturer : Eaton
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : BR Series
• Type : BR
• Voltage : 240
• Amperage : 70
• Phase : 1
• Poles : 2
• AIC rating : 10kA@240V
• Connection : Plug-In
• Functions : LI - Long-Time and Instantaneous Trip
• MCM Size : Min. Wire Size 14 AWG (Cu/Al) Max. Wire Size 4 AWG (Cu/Al)
• Breaker Type : BR
• Protection : Thermal Magnetic

Product Data

• UPC : 786676363150
• GTIN : 00786676363150
• Country of Origin : Dominican Republic
• Dimensions : 2.8 in x 2.5 in x 1.9 in (Length/Depth x Height x Width)
• Weight : 0.65
• Panel Type : Type BR Loadcenters
• Standards : UL 489
• Certification : UL 489
• Wire Size : AWG 8 to AWG 1/0, Cu/Al
