BR2125ST - Westinghouse 125A 120/240V 2-Pole Plug-On Shunt Trip Circuit Breaker 10kAIC BR Series

BR2125ST

BR2125ST is a Westinghouse 2-pole, 125 amp, 120/240 volt plug-on circuit breaker with shunt trip designed for Type BR loadcenters.

This thermal magnetic circuit breaker features a 10 kA interrupting rating, common breaker trip, and supports wire sizes from #4 to 2/0 AWG copper or aluminum. It mounts easily with a plug-on method and complies with UL 489 and Federal Specifications Classification W-C375.

Key Specifications
• Amperage Rating: 125 A
• Voltage Rating: 120/240 V
• Number of Poles: Two-pole
• Mounting Type: Plug-on
• Interrupt Rating: 10 kAIC
• Trip Type: Common breaker trip with shunt trip included
• Series/Frame: BR Series
• Wire Size: #4-2/0 AWG Cu/Al
• Certifications: UL 489
• Compliance: Federal Specifications Classification W-C375

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Additional Information

complete with 120V shunt trip

Specifications

• Part Number: BR2125ST
• Manufacturer : Westinghouse
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : BR Series
• Type : BR
• Voltage : 240
• Amperage : 125
• Phase : 1
• Poles : 2
• AIC rating : 10kA@240V
• Connection : Plug-In
• Functions : Long Time and Instantaneous
• Protection : Thermal Magnetic

Product Data

• UPC : 786676000420
• GTIN : 00786676000420
• Country of Origin : Dominican Republic
• Dimensions : 3.25 in x 3 in x 3 in (Length/Depth x Height x Width)
• Weight : 1
• Certification : UL 489,Federal Specifications Classification W-C375
• Wire Size : #4-2/0 AWG Cu/Al
