BR2100ST - Cutler Hammer 100A 2-Pole 120/240V BR Frame Plug-On Shunt Trip Circuit Breaker 42kAIC

BR2100ST

BR2100ST is a Cutler Hammer 100 Amp, 2-pole, 120/240 Volt BR frame circuit breaker with plug-on mounting and shunt trip feature.This Eaton BR thermal magnetic circuit breaker features a 42 kA interrupt rating, common breaker trip, and is designed for Type BR loadcenters. It supports #4-1/0 AWG copper/aluminum wiring and complies with UL 489 and Federal Specifications W-C375. The breaker measures approximately 3.25 x 3 x 3 inches and weighs about 1.4 lbs.

• Amperage: 100 A
• Voltage Rating: 120/240 V
• Poles: Two-pole
• Mounting Type: Plug-on
• Interrupt Rating: 42 kAIC
• Frame/Series: BR
• Trip Unit: Common breaker trip
• Shunt Trip: Included
• Wire Size: #4-1/0 AWG Cu/Al
• Certifications: UL 489, Federal Specifications W-C375
• Dimensions: 3.25 x 3 x 3 in
• Weight: 1.4 lbs

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Additional Information

complete with 120V shunt trip

Specifications

• Part Number: BR2100ST
• Manufacturer : Cutler Hammer
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : BR Series
• Type : BR
• Voltage : 240
• Amperage : 100
• Phase : 1
• Poles : 2
• AIC rating : 10kA@240V
• Connection : Plug-In
• Functions : LI - Long-Time and Instantaneous
• Protection : Thermal Magnetic

Product Data

• UPC : 786676000406
• GTIN : 00786676000406
• Country of Origin : Dominican Republic
• Dimensions : 3.25 in x 3 in x 3 in (Length/Depth x Height x Width)
• Weight : 1.4
• Certification : UL 489,Federal Specifications Classification W-C375
• Wire Size : 4 TO 1/0 AWG (ALUMINUM/COPPER)
