Product Info
- Manufacturer:Westinghouse
- Sub-Category:Molded Case
Description
BR120AF
BR120AF is a Westinghouse 20 amp, 120/240 Volt, single-pole thermal magnetic circuit breaker from the BR Series designed for reliable electrical protection.This molded case circuit breaker features a 10kA interrupting rating at 120V, plug-in mounting type, and supports wire sizes from 14 to 4 AWG for copper and aluminum conductors. It is UL 1699 certified and suitable for use in Type BR load centers, providing arc fault protection with a compact 1-inch width.
- Key Specifications
- Amperage: 20 A
- Voltage: 120/240 V
- Poles: 1
- Interrupt Rating: 10 kAIC @ 120 V
- Mounting Type: Plug-In
- Series/Frame: BR Series
- Trip Unit: Thermal Magnetic
- Wire Size: 14-4 AWG Cu/Al
- Certifications: UL 1699
- Type: Molded Case Circuit Breaker
- Arc Fault Protection: Yes
Specifications
- Part Number: BR120AF
- Manufacturer : Westinghouse
- Brand : Eaton
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : BR Series
- Type : BR
- Voltage : 120
- Amperage : 20
- Phase : 1
- Poles : 1
- AIC rating : 10kA@120V
- Connection : Plug-In
- Functions : LI - Long-Time and Instantaneous Trip
- Temp Rating : -13–158 °F (-25–70 °C)
- Protection : Thermal Magnetic
Product Data
- UPC : 78211423150
- GTIN : 00782114231500
- Country of Origin : United States
- Dimensions : 3 in x 1.25 in x 4.75 in (Length/Depth x Height x Width)
- Weight : 0.45
- Certification : UL 1699
- Wire Size : AWG 14 to AWG 4, Cu/Al
