BQC250220 - Eaton Cutler Hammer 2-Pole 20A 240V Molded Case Circuit Breaker, 10kA AIC, Plug-In Mount, BQC Series, Thermal Magnetic Trip

BQC250220

BQC250220 - Eaton Type BQC 1-inch CTL plug-on quadplex thermal magnetic circuit breaker with common trip, rated for two 50A poles and two 20A poles at 120/240V.This Eaton BQC250220 circuit breaker features plug-on mounting for Type BR loadcenters, includes rejection tab, and supports wire sizes #14-4 AWG Cu/Al. It provides four circuits in two spaces with 10 kAIC interrupt rating and is suitable for HACR applications.

• Part Number: BQC250220
• Manufacturer: Eaton
• Type: BQC 1-inch CTL plug-on
• Circuit Breaker Type: BQ, thermal magnetic
• Amperage: (2) 50A poles, (2) 20A poles
• Voltage: 120/240V AC
• Poles: 4
• Mounting: Plug-on
• Interrupt Rating: 10 kAIC
• Trip Type: Common breaker trip
• Wire Size: #14-4 AWG Cu/Al
• For Use With: Type BR loadcenters

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: BQC250220
• Manufacturer : Eaton
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : BQ Series
• Type : BQC
• Voltage : 240
• Amperage : 20
• Phase : 1
• Poles : 2
• AIC rating : 10kA@240V
• Connection : Plug-In
• Functions : LI - Long-Time and Instantaneous Trip
• Terminal Connection : Lug
• Protection : Thermal Magnetic

Product Data

• UPC : 786676006354
• GTIN : 00786676006354
• Country of Origin : Dominican Republic
• Dimensions : 3 in x 3 in x 2 in (Length/Depth x Height x Width)
• Weight : 0.9
• Standards : HACR Rated, UL Listed
• Certification : UL 489,Federal Specifications Classification W-C411
• Wire Size : AWG 14 to AWG 4, Cu/Al
