Product Info
- Manufacturer:Siemens
- Sub-Category:Molded Case
Description
BQ3B090HL
BQ3B090HL - Siemens 3-pole molded case circuit breaker with 90A rating and high 22kA interrupt capacity.The Siemens BQ3B090HL is a BQH frame thermal-magnetic circuit breaker rated at 240V AC, featuring bolt-on mounting, line and load side lugs, and 3-pole common-trip design for reliable electrical distribution protection against overloads and short circuits.
- Part Number: BQ3B090HL
- Manufacturer: Siemens
- Amperage Rating: 90A
- Voltage Rating: 240V AC
- Number of Poles: 3
- Frame Size: BQH
- Interrupt Rating: 22kA
- Trip Type: Thermal-Magnetic
- Mounting Type: Bolt-On
- Connection: Line and Load Lugs
Specifications
- Part Number: BQ3B090HL
- Manufacturer : Siemens
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : BQ Series
- Type : BQH
- Voltage : 240
- Amperage : 90
- Phase : 3
- Poles : 3
- AIC rating : 22kA@240V
- Connection : Feed-Thru
- Functions : LI - Long-Time and Instantaneous
- Terminal Connection : Lug
- Protection : Thermal Magnetic
Product Data
- UPC : 783643356702
- GTIN : 00783643356702
- Country of Origin : Mexico
- Dimensions : 2.756 x 2.756 x 3.937 inch
- Weight : 1.102
- Panel Type : Siemens Panelboards
- Standards : HACR Rated, UL Listed
- Certification : CSA, HACR, UL
