Product Info
- Manufacturer:Siemens
- Sub-Category:Molded Case
Description
BQ3B015H00S01
BQ3B015H00S01 - Siemens 3-pole molded case circuit breaker rated at 15A, 240V with bolt-on mounting.This BQ series BQH type breaker features a thermal-magnetic trip unit, 22kA interrupting rating at 240V, and includes load side lugs. Designed for panelboard applications requiring reliable overcurrent protection.
- Manufacturer: Siemens
- Part Number: BQ3B015H00S01
- Amperage: 15A
- Voltage: 240V AC
- Poles: 3
- Frame/Series: BQ
- Type: BQH
- Mounting: Bolt-On
- Interrupt Rating: 22kA at 240V
- Special Features: Load side lugs included
Additional Information
complete with 120V shunt trip
Specifications
- Part Number: BQ3B015H00S01
- Manufacturer : Siemens
- Brand : Siemens
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : BQ Series
- Type : BQH
- Voltage : 240
- Amperage : 15
- Phase : 3
- Poles : 3
- AIC rating : 22kA@240V
- Connection : Bolt-on
- Functions : LI - Long-Time and Instantaneous
- Terminal Connection : Lug
- Frame Size : 125A/BQ
- Temp Rating : -13‰ÛÒ158 å¡F (-25‰ÛÒ70 å¡C)
- MCM Size : Min. Wire Size 12 AWG (Al), 14 AWG (Cu) Max. Wire Size 10 AWG
- Breaker Type : Shunt Trip
- Protection : Thermal Magnetic
Product Data
- UPC : 662643649482
- GTIN : 00662643649482
- Country of Origin : Mexico
- Weight : 2.205
- Panel Type : Siemens Panelboards
- Standards : HACR Rated, UL Listed
- Certification : CSA, HACR, UL
