Product Info
- Manufacturer:Siemens
- Sub-Category:Molded Case
Description
BQ3B050HL
BQ3B050HL - Siemens BQ3B050HL 3-pole molded case circuit breaker with thermal-magnetic trip, rated at 50A and 240VAC.
This Siemens BQ frame circuit breaker features high instantaneous trip range (H), 3 poles, panel mounting, and load side lugs for bolt-on/lug-in/lug-out connections. It provides reliable overcurrent protection for electrical distribution and general purpose applications, sensing overcurrent, measuring its magnitude, and tripping to prevent damage to conductors.
Key Specifications
- Manufacturer: Siemens
- Frame/Series: BQ
- Amperage Rating: 50A
- Voltage Rating: 240VAC
- Number of Poles: 3
- Trip Type: Thermal-Magnetic
- Instantaneous Trip: High Range (H)
- Mounting Type: Panel
- Connection Type: Bolt-On/Lug-In/Lug-Out
- Wire Size: 8-6 AWG CU, 8-4 AWG AL
- Frequency: 50/60 Hz
At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.
Specifications
- Part Number: BQ3B050HL
- Manufacturer : Siemens
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : BQ Series
- Type : BQH
- Voltage : 240
- Amperage : 50
- Phase : 3
- Poles : 3
- AIC rating : 22kA@240V
- Connection : Feed-Thru
- Functions : LI - Long-Time and Instantaneous
- Terminal Connection : Lug
- Protection : Thermal Magnetic
Product Data
- UPC : 783643356665
- GTIN : 00783643356665
- Country of Origin : Mexico
- Dimensions : 2.756 x 2.756 x 3.937 inch
- Weight : 1.102
- Panel Type : Siemens Panelboards
- Standards : HACR Rated, UL Listed
- Certification : CSA, HACR, UL
