BQ3B040HL - Siemens 240V 40A 3 Pole Molded Case Circuit Breaker BQ Series 22kA Interrupt

BQ3B040HL

BQ3B040HL is a Siemens Type BQH Low Voltage Molded Case Circuit Breaker designed for general purpose electrical distribution and protection applications.

This 3-pole common-trip circuit breaker features thermal-magnetic trip protection with a high interrupt rating of 22 kA, making it suitable for demanding electrical environments. The breaker includes both line side and load side lugs for flexible installation options and supports bolt-on/lug-in/lug-out connections. It is rated for 240 VAC at 60 Hz frequency and accommodates wire sizes from 8 to 6 AWG copper or 8 to 4 AWG aluminum.

• Amperage Rating: 40 A continuous current
• Voltage Rating: 240 VAC
• Number of Poles: 3-Pole
• Interrupt Rating: 22 kA
• Trip Type: Thermal-Magnetic
• Breaker Type: Type BQH Low Voltage
• Frequency: 60 Hz
• Connection Type: Bolt-On/Lug-In/Lug-Out
• Wire Size: 8 to 6 AWG copper, 8 to 4 AWG aluminum
• Mounting Type: Panel
• Country of Origin: Mexico

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: BQ3B040HL
• Manufacturer : Siemens
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : BQ Series
• Type : BQH
• Voltage : 240
• Amperage : 40
• Phase : 3
• Poles : 3
• AIC rating : 22kA@240V
• Connection : Feed-Thru
• Functions : LI - Long-Time and Instantaneous
• Terminal Connection : Lug
• Protection : Thermal Magnetic

Product Data

• UPC : 783643356658
• GTIN : 00783643356658
• Country of Origin : Mexico
• Dimensions : 2.756 x 2.756 x 3.937 inch
• Weight : 1.102
• Panel Type : Siemens Panelboards
• Standards : HACR Rated, UL Listed
• Certification : CSA, HACR, UL
