BQ2B125 - Siemens 125 Amp 2 Pole 120/240V BQ Frame Bolt-On Circuit Breaker

BQ2B125

BQ2B125 is a Siemens Type BQ 2 pole thermal magnetic molded case circuit breaker rated for 125 amps at 120/240 volts with bolt-on connection and load side lugs. This breaker is designed for use in panelboards and provides long-time and instantaneous trip protection functions with a 10,000 ampere interrupting rating. The BQ2B125 is UL listed and CSA approved for reliable performance in residential and light commercial applications.

• Manufacturer: Siemens
• Part Number: BQ2B125
• Series: BQ
• Amperage: 125 Amps
• Voltage: 120/240 VAC
• Poles: 2
• Phase: 1
• Mounting Type: Bolt-On
• Connection: Load Side Lug
• Protection Type: Thermal Magnetic
• Trip Functions: Long-Time and Instantaneous
• Interrupting Rating: 10,000 AIC at 120/240 VAC
• Certifications: UL Listed, CSA Approved

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: BQ2B125
• Manufacturer : Siemens
• Brand : Siemens
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : BQ Series
• Type : BQ
• Voltage : 120/240
• Amperage : 125
• Phase : 1
• Poles : 2
• AIC rating : 10kA@240V
• Connection : Bolt-on
• Functions : LI - Long-Time and Instantaneous Trip
• Terminal Connection : Lug
• Frame Size : 125A/BQ
• Temp Rating : -13‰ÛÒ158 å¡F (-25‰ÛÒ70 å¡C)
• MCM Size : Min. Wire Size 12 AWG (Al), 14 AWG (Cu) Max. Wire Size 6 AWG
• Breaker Type : Standard
• Protection : Thermal Magnetic

Product Data

• UPC : 783643161245
• GTIN : 00783643161245
• Country of Origin : Mexico
• Dimensions : 2.563 x 2.00 x 3.972 inch
• Weight : 0.617
• Panel Type : Siemens Panelboards
• Standards : HACR Rated, UL Listed
• Certification : CSA, HACR, UL
