Product Info
- Manufacturer:Siemens
- Sub-Category:Molded Case
Description
BQ2B035QLD
BQ2B035QLD is a Siemens 2-pole molded case circuit breaker rated for 35 amps and 120/240 volts AC with thermal magnetic trip protection.This circuit breaker features a 10 kA interrupt rating and Insta-Wire terminals for quick installation. It is designed for low voltage electrical distribution and general purpose applications, meeting UL 489 and HACR certifications. The breaker is part of the Siemens BQ series, providing reliable circuit protection with a thermal-magnetic trip unit.
- Amperage: 35 A
- Voltage: 120/240 VAC
- Poles: 2
- Interrupt Rating: 10 kA
- Trip Unit: Thermal Magnetic
- Mounting Type: Molded Case
- Series/Frame: BQ
- Certifications: UL 489, HACR Rated
- Insta-Wire terminals for easy wiring
- General purpose and electrical distribution use
Specifications
- Part Number: BQ2B035QLD
- Manufacturer : Siemens
- Brand : Siemens
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : BQ Series
- Type : BQ
- Voltage : 240
- Amperage : 35
- Phase : 1
- Poles : 2
- AIC rating : 10kA@240V
- Connection : Bolt-On
- Functions : Long Time and Instantaneous Trip
- Terminal Connection : Lug
- Protection : Thermal Magnetic
Product Data
- UPC : 783643411845
- GTIN : 00783643411845
- Country of Origin : Mexico
- Dimensions : 3.937 x 1.969 x 2.756 inch
- Weight : 0.309
- Panel Type : Siemens Panelboards
- Standards : HACR Rated, UL Listed
- Certification : CSA, HACR, UL
