Product Info
- Manufacturer:Eaton
- Sub-Category:Breaker Type
Description
BPHMCP100R3CGN
BPHMCP100R3CGN is a 100% rated, 800 A, three-pole bus plug designed for Eaton Pow-R-Way III busway systems, providing maximum flexibility and reliability in power distribution applications. This bus plug features a dual plug-in stab design for easy installation and secure connection to Pow-R-Way III plug-in busway, and is compatible with PXR 10 trip units for advanced protection and monitoring. The BPHMCP100R3CGN is engineered for indoor or sprinkler-proof environments and meets UL 857 requirements. It supports wire sizes from 3/0 to 400 kcmil per phase and is suitable for use in demanding industrial and commercial installations. The unit is designed to deliver full current capacity without requiring oversizing, helping to reduce project costs and simplify installation.
- 100% rated for 800 A continuous current
- Three-pole configuration
- Compatible with Pow-R-Way III busway
- Dual plug-in stab bases for flexible mounting
- PXR 10 trip unit for advanced protection
- Indoor or sprinkler-proof rated
- UL 857 listed
- Interrupting rating: 35 kA at 480 V
- Wire range per phase: 3/0–400 kcmil
- Ground wire range: #4–600 kcmil
- Neutral wire range: #4–600 kcmil
- Weight: 250 lb
Specifications
- Part Number: BPHMCP100R3CGN
- Manufacturer : Eaton
- Category : Bus Plug
- Item Subcategory : Breaker Type
- Family : Standard Design
- Type : BPHMCP
- Voltage : 600
- Amperage : 100
- Phase : 3
- AIC rating : 65kA@480V
- Wire : 4
- Compatible Frames : HMCP
Product Data
- Weight : 40
