Product Info
- Manufacturer:Eaton
- Sub-Category:Breaker Type
Description
BPED3090G
BPED3090G is an Eaton Pow-R-Way III bus plug designed for reliable power distribution with a 90 Amp rating and 600 Volt maximum voltage.This three-pole bus plug features an F Frame breaker style suitable for Pow-R-Way III busway systems. It supports a maximum voltage of 600 VAC and an interrupt rating of 25 kA at 600 VAC, 100 kA at 480 VAC, and 100 kA at 240 VAC, ensuring high fault current withstand capability. The plug is engineered with a lightweight aluminum housing and epoxy insulation for enhanced conductor and system protection. It is polarized to prevent improper installation and designed for efficient energy use with lower voltage drop compared to cable and conduit.
- Key Specifications
- Manufacturer: Eaton
- Series: Pow-R-Way III
- Amperage: 90 Amp
- Voltage: 600 VAC max
- Poles: Three Pole
- Frame: F Frame (15-225 A range)
- Interrupt Rating: 25 kA at 600 VAC, 100 kA at 480 VAC, 100 kA at 240 VAC
- Mounting Type: Plug-in unit for busway
- Housing: Lightweight aluminum
- Insulation: Epoxy process
- Polarized design to prevent incorrect installation
Specifications
- Part Number: BPED3090G
- Manufacturer : Eaton
- Category : Bus Plug
- Item Subcategory : Breaker Type
- Family : Standard Design
- Type : BPED
- Voltage : 240
- Amperage : 90
- Phase : 3
- AIC rating : 65kA@240V
- Wire : 3
- Compatible Frames : ED
Product Data
- Weight : 40
