BJA260904 - Schneider Electric 90A 600V 2 Pole PowerPact B Circuit Breaker I-Line Plug-In

BJA260904

BJA260904 is a Schneider Electric 2 pole PowerPact B molded case circuit breaker rated for 90 amps and 600 volts AC with I-Line plug-in mounting.This thermal magnetic circuit breaker features a 65kA interrupting rating at 480V, suitable for industrial and commercial power distribution applications. It complies with IEC 60947-2 and UL 489 standards, providing reliable overcurrent protection with a compact B-frame design.

• Amperage: 90A
• Voltage Rating: 600V AC
• Poles: 2
• Mounting Type: I-Line Style Plug-In
• Interrupt Rating: 65kA at 480V
• Series/Frame: PowerPact B
• Trip Unit: Thermal Magnetic
• Certifications: IEC 60947-2, UL 489
• Frequency: 50/60 Hz
• Application: Industrial/Commercial Power Distribution

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: BJA260904
• Manufacturer : Schneider Electric
• Brand : Schneider Electric
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Powerpact
• Type : BJA
• Voltage : 600
• Amperage : 90
• Phase : 1
• Poles : 2
• AIC rating : 65kA@480V
• Connection : I-Line Style Plug-In
• Functions : LI - Long-Time and Instantaneous
• Temp Rating : -13–158 °F (-25–70 °C)
• Protection : Thermal Magnetic

Product Data

• Country of Origin : United States
• Dimensions : 5.4 in (137 mm) x 2.1 in (54 mm) x 3.5 in (89 mm) (Height x Width x Depth)
• Weight : 2.899
• Standards : NMX J-266, UL 489, EN/IEC 60947-5-1, NEMA AB1, EN/IEC 60947-2, GB 14048.2, CSA C22.2 No 5
• Certification : UL, IEC, CCC, EAC, CSA, NOM
• Wire Size : AWG 14...AWG 2/0 aluminium/copper
