BJA260804 - Schneider Electric PowerPact B 80A 2 Pole Circuit Breaker 600VAC 25kA Thermal Magnetic

BJA260804

BJA260804 is a 2 pole, 80A PowerPact B molded case circuit breaker designed for reliable protection in commercial and industrial power distribution systems. This breaker features a thermal magnetic trip unit, 600VAC voltage rating, and a 25kA interrupt rating at 600Y/347VAC. It is suitable for I-Line mounting and dual rated for AC/DC applications. The BJA260804 is UL, CSA, NOM, IEC, CCC certified, and CE marked for broad compliance.

• Part Number: BJA260804
• Manufacturer: Schneider Electric
• Series/Frame: PowerPact B
• Amperage: 80A
• Poles: 2 Pole
• Voltage Rating: 600VAC
• Interrupt Rating: 25kA @ 600Y/347VAC
• Mounting Type: I-Line
• Trip Unit: Thermal Magnetic
• Continuous Current Rating: 80%
• Certifications: UL, CSA, NOM, IEC, CCC, CE
• Application: AC/DC Dual Rated

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: BJA260804
• Manufacturer : Schneider Electric
• Brand : Schneider Electric
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Powerpact
• Type : BJA
• Voltage : 600
• Amperage : 80
• Phase : 1
• Poles : 2
• AIC rating : 65kA@480V
• Connection : I-Line Style Plug-In
• Functions : LI - Long-Time and Instantaneous
• Temp Rating : -13–158 °F (-25–70 °C)
• Protection : Thermal Magnetic

Product Data

• UPC : 606486118958
• GTIN : 03606490000000
• Dimensions : 5.4 in (137 mm) x 2.1 in (54 mm) x 3.5 in (89 mm) (Height x Width x Depth)
• Weight : 2.899
• Standards : CSA C22.2 No 5, EN/IEC 60947-2, EN/IEC 60947-5-1, NMX J-266, NEMA AB1, UL 489, GB 14048.2
• Certification : UL, IEC, CCC, EAC, CSA, NOM
• Wire Size : AWG 14...AWG 2/0 aluminium/copper
