BJA260154 - Schneider Electric 15A 2 Pole 600V I-Line Circuit Breaker 25kA Interrupt Rating Thermal Magnetic

BJA260154

BJA260154 is a Schneider Electric 15 amp, 2 pole circuit breaker designed for 600 Volt I-Line applications with a 25kA interrupt rating.This PowerPact B series circuit breaker features thermal magnetic trip units, suitable for distribution use with a toggle control type. It supports a 600Y/347V AC voltage rating and offers reliable protection with a breaking capacity code J and interrupt ratings up to 100kA at 240V AC. The breaker is designed for plug-in mounting in I-Line panels and complies with UL 489 standards.

• Amperage: 15 A
• Voltage Rating: 600Y/347V AC
• Number of Poles: 2
• Mounting Type: I-Line Plug-In
• Interrupt Rating: 25kA at 600Y/347V, 100kA at 240V AC
• Series/Frame: PowerPact B
• Trip Unit: Thermal Magnetic
• Breaking Capacity Code: J
• Control Type: Toggle
• Certifications: UL 489

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: BJA260154
• Manufacturer : Schneider Electric
• Brand : Schneider Electric
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Powerpact
• Type : BJA
• Voltage : 600
• Amperage : 15
• Phase : 1
• Poles : 2
• AIC rating : 65kA@480V
• Connection : I-Line Style Plug-In
• Functions : LI - Long-Time and Instantaneous
• Temp Rating : -13–158 °F (-25–70 °C)
• Protection : Thermal Magnetic

Product Data

• UPC : BJA260154
• GTIN : 03606486118931
• Dimensions : 5.4 in (137 mm) x 2.1 in (54 mm) x 3.5 in (89 mm) (Height x Width x Depth)
• Weight : 2.899
• Standards : UL 489, NMX J-266, GB 14048.2, EN/IEC 60947-2, NEMA AB1, CSA C22.2 No 5, EN/IEC 60947-5-1
• Certification : UL, IEC, CCC, EAC, CSA, NOM
• Wire Size : AWG 14...AWG 2/0 aluminium/copper
