BGA34100Y - Square D PowerPacT B-Frame 100A 3-Pole 480Y/277VAC Molded Case Circuit Breaker

BGA34100Y

BGA34100Y is a Square D PowerPacT B-Frame molded case circuit breaker providing 100 amps of thermal magnetic protection for 3-pole applications at 480Y/277VAC.This circuit breaker features a 35kA interrupt rating at 480Y/277VAC, I-Line mounting with line side I-Line terminations and load side mechanical lugs, and an 80% continuous current rating with ABC phase connection. It includes dual-break rotating contacts to reduce peak short circuit current and a manual push-to-trip button. The breaker complies with UL, CSA, NOM, IEC standards, and is CE marked.

Key Specifications
• Amperage: 100A
• Voltage Rating: 480Y/277VAC
• Poles: 3
• Frame: PowerPacT B-Frame
• Mounting Type: I-Line
• Interrupt Rating: 35kA at 480Y/277VAC
• Trip Unit: Thermal Magnetic
• Continuous Current Rating: 80% ABC
• Dimensions (HxWxD): 5.39 x 3.19 x 3.50 inches
• Weight: 2.9 lbs
• Certifications: UL, CSA, NOM, IEC, CE

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: BGA34100Y
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Powerpact
• Type : BGA
• Voltage : 480
• Amperage : 100
• Phase : 3
• Poles : 3
• AIC rating : 18kA@480V
• Connection : I-Line Style Plug-In
• Functions : LI - Long-Time and Instantaneous
• Terminal Connection : Al Mechanical Lug OFF End, I-Line ON End
• Frame Size : 125A/BG
• Temp Rating : -13–158 °F (-25–70 °C)
• MCM Size : Min. Wire Size 14 AWG Max. Wire Size 2 AWG
• Breaker Type : Standard
• Protection : Thermal Magnetic
• Phase Connection : ABC

Product Data

• UPC : 785901069522
• GTIN : 00785901069522
• Country of Origin : Mexico
• Dimensions : 5.4 in (137 mm) x 3.2 in (81 mm) x 3.5 in (89 mm) (Height x Width x Depth)
• Weight : 3.9
• Panel Type : Electrical Distribution Equipment, Industrial Control Panels
• Standards : EN/IEC 60947-5-1, NMX J-266, GB 14048.2, NEMA AB1, UL 489, CSA C22.2 No 5, EN/IEC 60947-2
• Certification : UL, IEC, CCC, EAC, CSA, NOM
• Wire Size : AWG 14...AWG 2/0 aluminium/copper
