BF230H - Siemens 30A 2-Pole GFCI Circuit Breaker 120/240V AC 22kA

BF230H

BF230H is a 2-pole, 30 ampere ground fault circuit interrupter (GFCI) circuit breaker designed for Siemens panelboards. This breaker provides reliable protection for 120/240V AC circuits and features a high interrupting rating for demanding applications. The BF230H is a molded case circuit breaker with a toggle actuator and bolt-on mounting style. It is engineered for use in commercial and industrial environments where ground fault protection is required. The breaker is rated for 120/240V AC and offers a 22kA interrupting rating at 120/240V AC, ensuring safety and durability.

• Part Number: BF230H
• Manufacturer: Siemens
• Type: GFCI Circuit Breaker
• Amperage: 30A
• Poles: 2
• Voltage: 120/240V AC
• Interrupting Rating: 22kA @ 120/240V AC
• Mounting Style: Bolt On
• Actuator: Toggle
• Series/Frame: BLHF
• Trip Sensitivity: 5mA
• Phase: 1

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: BF230H
• Manufacturer : Siemens
• Brand : Siemens
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : BL Series
• Type : BLHF
• Voltage : 120/240
• Amperage : 30
• Phase : 1
• Poles : 2
• AIC rating : 22kA@240V
• Connection : Bolt-on
• Functions : LI - Long-Time and Instantaneous
• Terminal Connection : Lug
• Frame Size : 60A/BLHF
• MCM Size : Min. Wire Size 12 AWG (Al), 14 AWG (Cu) Max. Wire Size 6 AWG
• Breaker Type : Ground Fault Circuit Interrupter (Class A - 5mA)
• Protection : Thermal Magnetic

Product Data

• UPC : 783643274068
• GTIN : 00783643274068
• Country of Origin : Philippines
• Dimensions : 1.969 x 3.937 x 5.906 inch
• Weight : 1.102
• Panel Type : Siemens Panelboards
• Standards : CSA Certified, HACR Rated, NOM Certified, UL Listed
• Certification : CSA Certified, HACR Rated, NOM Certified, UL Listed
