BDA34015Y - Schneider Electric PowerPact B Circuit Breaker 15A 3 Pole 480Y/277V AC 18kA I-Line Thermal Magnetic

BDA34015Y

BDA34015Y is a Schneider Electric PowerPact B circuit breaker rated for 15 amps, 3 poles, and 480Y/277 volts AC with an 18kA interrupt rating and I-Line mounting.This thermal magnetic circuit breaker features an 80% continuous current rating with ABC trip unit, designed for reliable protection in industrial and commercial electrical distribution systems. It supports 3-pole I-Line mounting and complies with UL 489 certification standards.

Key Specifications
• Amperage: 15A
• Voltage: 480Y/277V AC
• Poles: 3
• Interrupt Rating: 18kA at 480/277V AC
• Mounting Type: I-Line
• Trip Unit: Thermal Magnetic, 80% rated
• Series/Frame: PowerPact B
• Certifications: UL 489
• Continuous Current Rating: 80%
• Type: Molded Case Circuit Breaker

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: BDA34015Y
• Manufacturer : Schneider Electric
• Brand : Schneider Electric
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Powerpact
• Type : BDA
• Voltage : 480
• Amperage : 15
• Phase : 3
• Poles : 3
• AIC rating : 18kA@480V
• Connection : I-Line Style Plug-In
• Functions : Long Time and Instantaneous Trip
• Terminal Connection : Al Mechanical Lug OFF End, I-Line ON End
• Frame Size : 125A/BD
• Temp Rating : -13–158 °F (-25–70 °C)
• MCM Size : Min. Wire Size 14 AWG Max. Wire Size 2 AWG
• Breaker Type : Standard
• Protection : Thermal Magnetic
• Phase Connection : ABC

Product Data

• UPC : 785901009030
• GTIN : 03606481152350
• Country of Origin : Mexico
• Dimensions : 5.4 in (137 mm) x 3.2 in (81 mm) x 3.5 in (89 mm) (Height x Width x Depth)
• Weight : 4.2
• Panel Type : Electrical Distribution Equipment, Industrial Control Panels
• Standards : NMX J-266, GB 14048.2, CSA C22.2 No 5, EN/IEC 60947-2, EN/IEC 60947-5-1, NEMA AB1, UL 489
• Certification : UL, IEC, CCC, EAC, CSA, NOM
• Wire Size : AWG 14...AWG 2/0 aluminium/copper
