BDA34050Y - Schneider Electric PowerPact B 50A 3 Pole 480Y/277 VAC Circuit Breaker I-Line Thermal Magnetic

BDA34050Y

This I-Line mounted breaker features an 18 kA interrupt rating at 480Y/277 VAC, 80% continuous current rating, and is designed for use with 14 to 2/0 AWG aluminum or copper wire. It includes a toggle actuator, mechanical lug connection, and is UL, CSA, NOM, IEC, CCC certified and CE marked. The breaker operates in temperatures from -13 to 158 degrees Fahrenheit and has an IP40/IK07 enclosure rating.

Key Specifications
• Amperage: 50 A
• Voltage Rating: 480Y/277 VAC
• Poles: 3
• Mounting Type: I-Line
• Interrupt Rating: 18 kA at 480Y/277 VAC
• Series/Frame: PowerPact B-Frame
• Trip Unit: Thermal Magnetic
• Continuous Current Rating: 80%
• Wire Range: 14 to 2/0 AWG Al/Cu
• Certifications: UL, CSA, NOM, IEC, CCC, CE
• Enclosure Rating: IP40/IK07
• Operating Temperature: -13 to 158 °F

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.




Specifications

• Part Number: BDA34050Y
• Manufacturer : Schneider Electric
• Brand : Schneider Electric
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Powerpact
• Type : BDA
• Voltage : 480
• Amperage : 50
• Phase : 3
• Poles : 3
• AIC rating : 18kA@480V
• Connection : I-Line
• Functions : LI - Long-Time and Instantaneous
• Terminal Connection : Al Mechanical Lug OFF End, I-Line ON End
• Frame Size : 125A/BD
• Temp Rating : -13–158 °F (-25–70 °C)
• MCM Size : Min. Wire Size 14 AWG Max. Wire Size 2 AWG
• Breaker Type : Standard
• Protection : Thermal Magnetic
• Phase Connection : ABC



Product Data

• UPC : 785901000198
• GTIN : 03606481152428
• Country of Origin : Mexico
• Dimensions : 5.4 in (137 mm) x 3.2 in (81 mm) x 3.5 in (89 mm) (Height x Width x Depth)
• Weight : 4.17
• Panel Type : Electrical Distribution Equipment, Industrial Control Panels
• Standards : GB 14048.2, CSA C22.2 No 5, EN/IEC 60947-2, UL 489, NMX J-266, EN/IEC 60947-5-1, NEMA AB1
• Certification : UL, IEC, CCC, EAC, CSA, NOM
• Wire Size : AWG 14...AWG 2/0 aluminium/copper
