B245H00S01 - Siemens 45A 120/240V 2 Pole Bolt-On Circuit Breaker BL Frame 22kAIC

B245H00S01

B245H00S01 is a Siemens 2 pole, 45 amp, 120/240 volt bolt-on circuit breaker from the BL series with a 22kA interrupt rating.This Siemens B245H00S01 circuit breaker features a BL frame type with thermal magnetic trip unit protection for overload and short circuit. It is designed for use in AC systems up to 120/240 volts and has a 22,000 amp interrupting capacity at 240 volts. The breaker mounts with a bolt-on style and is suitable for residential, commercial, and light industrial applications.

• Amperage: 45A
• Voltage: 120/240V AC
• Number of Poles: 2
• Mounting Type: Bolt-On
• Interrupt Rating: 22kA at 240V
• Frame Type: BL
• Trip Unit: Thermal Magnetic
• Series: BL Series
• Phase: Single Phase
• Certifications: UL Listed

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Additional Information

complete with 120V shunt trip

Specifications

• Part Number: B245H00S01
• Manufacturer : Siemens
• Brand : Siemens
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : BL Series
• Type : BLH
• Voltage : 120/240
• Amperage : 45
• Phase : 1
• Poles : 2
• AIC rating : 22kA@240V
• Connection : Bolt-On
• Functions : Long Time and Instantaneous Trip
• Terminal Connection : Lug
• Frame Size : 125A/BLH
• Temp Rating : -13‰ÛÒ158 å¡F (-25‰ÛÒ70 å¡C)
• MCM Size : Min. Wire Size 12 AWG (Al), 14 AWG (Cu) Max. Wire Size 6 AWG
• Breaker Type : Shunt Trip
• Protection : Thermal Magnetic

Product Data

• UPC : 783643524750
• GTIN : 00783643524750
• Country of Origin : Mexico
• Dimensions : 3 in x 2 in x 2 in
• Weight : 0.705
• Panel Type : Siemens P1 Panelboards
• Standards : CSA Certified, HACR Rated, NOM Certified, UL Listed
• Certification : CSA Certified, HACR Rated, NOM Certified, UL Listed
