B22500S01 - Siemens 25 Amp 240 Volt 2-Pole BL Series Circuit Breaker with 120 Volt Shunt Trip

B22500S01

B22500S01 is a Siemens 25 Amp 240 Volt 2-Pole BL Series circuit breaker featuring a 120 Volt shunt trip for enhanced control and safety.This Siemens B22500S01 breaker is a bolt-on type molded case circuit breaker designed for 120/240 Volt AC systems. It has a 25 Amp rating, 2 poles, and a 10 kA interrupting rating at 240 Volts. The breaker belongs to the BL series/frame and includes a 120 Volt shunt trip for remote tripping capability. It mounts via bolt-on installation and is suitable for panel mounting with busbar line side and lug load side terminations.

Key Specifications
• Amperage: 25 Amp
• Voltage: 120/240 Volt AC
• Poles: 2
• Interrupt Rating: 10 kA @ 240V
• Series/Frame: BL
• Trip Unit: 120 Volt Shunt Trip
• Mounting Type: Bolt-On
• Line Side Termination: Busbar
• Load Side Termination: Lug (Included)
• Panel Mounted Molded Case Circuit Breaker
At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.


Additional Information

complete with 120V shunt trip




Specifications

• Part Number: B22500S01
• Manufacturer : Siemens
• Brand : Siemens
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : BL Series
• Type : BL
• Voltage : 240
• Amperage : 25
• Phase : 1
• Poles : 2
• AIC rating : 10kA@240V
• Connection : Bolt-on
• Functions : Long Time and Instantaneous Trip
• Terminal Connection : Lug
• Frame Size : 125A/BL
• Temp Rating : -13‰ÛÒ158 å¡F (-25‰ÛÒ70 å¡C)
• MCM Size : Min. Wire Size 12 AWG (Al), 14 AWG (Cu) Max. Wire Size 6 AWG
• Breaker Type : Shunt Trip
• Protection : Thermal Magnetic



Product Data

• UPC : 783643089297
• GTIN : 00783643089297
• Country of Origin : Mexico
• Dimensions : 3.937 x 3.937 x 5.906 inch
• Weight : 0.375
• Panel Type : Siemens P1 Panelboards
• Standards : CSA Certified, HACR Rated, NOM Certified, UL Listed
• Certification : CSA Certified, HACR Rated, NOM Certified, UL Listed
