B160HH - Siemens 60A 120V 1 Pole Bolt-On Circuit Breaker 65kA Interrupt Rating HBL Frame

B160HH

B160HH is a Siemens 60 amp, 120 volt, 1 pole bolt-on circuit breaker with a 65kA interrupt rating and HBL frame.This Siemens B160HH circuit breaker features a bolt-on mounting type, suitable for AC voltage applications at 120 volts. It has a single pole design with a 60 ampere rating and a high interrupting capacity of 65,000 amperes at 240 volts. The breaker is UL listed, HACR rated, and CSA certified for reliable performance and safety compliance.

Key Specifications
• Manufacturer: Siemens
• Part Number: B160HH
• Amperage: 60A
• Voltage: 120V AC
• Poles: 1
• Mounting Type: Bolt-On
• Interrupt Rating: 65kA @ 240V
• Frame Type: HBL
• Certifications: UL Listed, HACR, CSA Certified

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: B160HH
• Manufacturer : Siemens
• Brand : Siemens
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : BL Series
• Type : HBL
• Voltage : 120
• Amperage : 60
• Phase : 1
• Poles : 1
• AIC rating : 65kA@240V
• Connection : Bolt-on
• Functions : LI - Long-Time and Instantaneous
• Terminal Connection : Lug
• Frame Size : 125A/BL
• MCM Size : Min. Wire Size 12 AWG (Al), 14 AWG (Cu) Max. Wire Size 10 AWG
• Breaker Type : Standard
• Protection : Thermal Magnetic

Product Data

• UPC : 783643088283
• GTIN : 00783643088283
• Country of Origin : Mexico
• Dimensions : 2.563 x 1.00 x 3.122 inch
• Weight : 0.315
• Panel Type : Siemens P1 Panelboards
• Standards : CSA Certified, HACR Rated, NOM Certified, UL Listed
• Certification : CSA Certified, HACR Rated, NOM Certified, UL Listed
