Product Info
- Manufacturer:Siemens
- Sub-Category:Molded Case
Description
B14000S01
B14000S01 - Siemens 40 Amp 1-Pole BL bolt-on circuit breaker with 120VAC shunt trip.This thermal magnetic circuit breaker from Siemens BL series features bolt-on mounting for P1 panelboards, 10 kA interrupt rating at 120V AC, and toggle actuator for reliable electrical distribution protection.
- Part Number: B14000S01
- Manufacturer: Siemens
- Amperage: 40A
- Voltage: 120VAC
- Poles: 1
- Mounting Type: Bolt-On
- Interrupt Rating: 10 kA @ 120V AC
- Series/Frame: BL
- Trip Unit: Shunt Trip 120VAC
- Certifications: UL Listed
Specifications
- Part Number: B14000S01
- Manufacturer : Siemens
- Brand : Siemens
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : BL Series
- Type : BL
- Voltage : 240
- Amperage : 40
- Phase : 1
- Poles : 1
- AIC rating : 10kA@240V
- Connection : Bolt-on
- Functions : LI - Long-Time and Instantaneous
- Terminal Connection : Lug
- Frame Size : 125A/BL
- MCM Size : Min. Wire Size 12 AWG (Al), 14 AWG (Cu) Max. Wire Size 10 AWG
- Breaker Type : Shunt Trip
- Protection : Thermal Magnetic
Product Data
- UPC : 783643088566
- GTIN : 00783643088566
- Country of Origin : Mexico
- Dimensions : 5.906 x 3.937 x 2.756 inch
- Weight : 2.006
- Panel Type : Siemens P1 Panelboards
- Standards : CSA Certified, HACR Rated, NOM Certified, UL Listed
- Certification : CSA Certified, HACR Rated, NOM Certified, UL Listed
