Product Info
- Manufacturer:Siemens
- Sub-Category:Molded Case
Description
B115AFCH
B115AFCH - Siemens 15 Amp 1-Pole Bolt-On Combination Arc-Fault Circuit Interrupter (AFCI) breaker for BL type load centers, rated at 120/240V AC and 22 kA interrupt rating.
This thermal magnetic circuit breaker provides arc fault protection with exclusive LED trip indicator, designed for bolt-on mounting in Siemens single phase panelboards and load centers. It features UL Listed QAFH type classification and supports wire range #14-#8 AWG Cu or #12-#8 AWG Al with 25 lb-in torque rating.
Key Specifications
- Amperage: 15A
- Poles: 1
- Voltage AC: 120/240V
- Mounting Type: Bolt-On
- Interrupt Rating AC: 22 kA
- Family/Style/Frame: BL
- Trip Unit: Thermal Magnetic, Combination AFCI
- UL Type: QAFH, BAFH
At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.
Specifications
- Part Number: B115AFCH
- Manufacturer : Siemens
- Brand : Siemens
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : BL Series
- Type : HBAF
- Voltage : 120
- Amperage : 15
- Phase : 1
- Poles : 1
- AIC rating : 22kA@120V
- Connection : Bolt-On
- Functions : Long Time and Instantaneous Trip
- Temp Rating : -13‰ÛÒ158 å¡F (-25‰ÛÒ70 å¡C)
- Protection : Thermal Magnetic
Product Data
- UPC : 783643970779
- Country of Origin : Philippines
- Dimensions : 5.906 x 3.937 x 0.787 inch
- Weight : 0.397
- Panel Type : Siemens P1 Panelboards
- Standards : CSA Certified, HACR Rated, NOM Certified, UL Listed
- Certification : CSA Certified, HACR Rated, NOM Certified, UL Listed
