Product Info
- Manufacturer:Schneider Electric
- Sub-Category:Rating Plug
Description
ARP070
ARP070 is a circuit breaker rating plug designed to derate the output amperage of compatible Schneider Electric circuit breakers to 70% of the CT sensor rating. This plug is a direct replacement for the original Square D ARP070 and is suitable for use with MicroLogic Series 3B solid state electronic trip units. The ARP070 rating plug is field installable and interchangeable, providing a reliable solution for adjusting breaker ratings in molded case frame types equipped with MicroLogic trip units. It is engineered for seamless integration and consistent performance in commercial and industrial applications.
- Part Number: ARP070
- Manufacturer: Schneider Electric
- Type: Rating Plug
- Amperage: 70%
- Compatible Trip Unit: MicroLogic Series 3B
- Series/Frame: Molded Case Frame Types
- Mounting Type: Field Installable
- Application: Circuit Breaker Amperage Derating
- Direct Replacement for: Square D ARP070
- Interchangeable: Yes
Specifications
- Part Number: ARP070
- Manufacturer : Schneider Electric
- Brand : Square D
- Category : Circuit Breaker
- Item Subcategory : Rating Plug
- Family : Micrologic
- Type : ARP
- Amperage : 4000
- Frame Size : 4000
- Amperage Maximum : 4000
- Amperage Minimum : 100
- Compatible Frames : LX,LXP,LXL,LXF,LE,LEP,LEL,LEF,MX,MXP,MXL,MXF,ME,MEP,MEL,MEF,NX,NXL,NXP,NXF,NE,NEL,NEP,NEF,PX,PXF,PXL,PXP,PE,PEL,PEP,PEF,SED,SEHD,SEF,SEHF
- Trip Type : Micrologic
Product Data
- Weight : 1
