ARP056 - Schneider Electric Circuit Breaker Rating Plug for Micrologic Series B Trip Unit, 56% Sensor Multiplier

ARP056

ARP056 is a Schneider Electric circuit breaker rating plug designed for use with Micrologic Series B trip units to derate circuit breaker output amperage to 56% of the CT sensor rating.ARP056 rating plug provides a sensor multiplier value of 0.563 (56.3%), allowing precise adjustment of the maximum amperage sensed by the trip unit. This plug is field installable and interchangeable, ensuring compatibility and ease of use in electronic trip molded case circuit breakers.

Key Specifications
• Manufacturer: Schneider Electric
• Part Number: ARP056
• Type: Circuit Breaker Rating Plug
• Sensor Multiplier: 0.563 (56.3%)
• Compatible with Micrologic Series B Trip Units
• Function: Derates max amp output to 56% of CT sensor rating
• Field installable and interchangeable
• Used in electronic trip molded case circuit breakers
• Weight: Approximately 0.10 lbs
• Certifications: UL Listed, CSA Certified (per trip unit and breaker standards)

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: ARP056
• Manufacturer : Schneider Electric
• Brand : Schneider Electric
• Category : Circuit Breaker
• Item Subcategory : Rating Plug
• Family : Micrologic
• Type : ARP
• Amperage : 4000
• Frame Size : 4000
• Amperage Maximum : 4000
• Amperage Minimum : 100
• Compatible Frames : LX,LXP,LXL,LXF,LE,LEP,LEL,LEF,MX,MXP,MXL,MXF,ME,MEP,MEL,MEF,NX,NXL,NXP,NXF,NE,NEL,NEP,NEF,PX,PXF,PXL,PXP,PE,PEL,PEP,PEF,SED,SEHD,SEF,SEHF
• Trip Type : Micrologic

Product Data

• Weight : 1
