AN56KN0A - Cutler Hammer Eaton Freedom NEMA Motor Control Starter 90A 3-Pole 600VAC Reversing Reset Overload Relay

AN56KN0A

AN56KN0A is a Cutler Hammer Eaton Freedom NEMA motor control starter designed for reversing motor control applications.This motor starter features a 90 amp rating, 3-pole configuration, and supports up to 600 VAC operation. It includes a reversing reset overload relay and is suitable for motors up to 50 horsepower at 480/600 volts. The coil voltage is 110 to 120 VAC, and it is designed for 50/60 Hz frequency. The starter is NEMA Size 3 with a horizontal open mounting type and offers robust durability with 2,000,000 electrical and 20,000,000 mechanical operations. It complies with relevant certifications for industrial motor control.

Key Specifications
• Amperage: 90 A
• Voltage: 600 VAC max
• Poles: 3
• Mounting Type: Horizontal Open
• Interrupt Rating: Designed for heavy-duty motor control
• Series/Frame: Eaton Freedom NEMA Size 3
• Trip Unit: Reversing Reset Overload Relay
• Horsepower Ratings: 25 HP at 208V, 30 HP at 240V, 50 HP at 480/600V
• Coil Voltage: 110-120 VAC
• Frequency: 50/60 Hz
• Durability: 2,000,000 electrical and 20,000,000 mechanical operations
• Certifications: Industry standard motor control certifications
At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.


Specifications

• Part Number: AN56KN0A
• Manufacturer : Cutler Hammer
• Brand : Cutler Hammer
• Category : Motor Control
• Item Subcategory : Motor Starter
• Family : Freedom Series
• Type : AN56
• Voltage : 600
• Amperage : 90
• Phase : 3
• Poles : 3
• Coil Voltage Maximum : 120
• Coil Voltage Minimum : 110
• Nema Rating : 00



Product Data

• UPC : 782113603902
• GTIN : 00782113603902
• Country of Origin : Dominican Republic
• Dimensions : 6.75 in x 4.63 in x 6.63 in (Length/Depth x Height x Width)
• Weight : 9.3 lb
• Certification : UL Listed,CSA Certified
