AN16NN0A - Cutler Hammer 135A 600V 3-Pole Freedom Series NEMA 4 Motor Starter

AN16NN0A

AN16NN0A is a Cutler Hammer Freedom Series motor starter designed for full voltage, non-reversing motor control applications.This 3-pole, 135 amp motor starter features a NEMA Size 4 open enclosure with horizontal surface mounting. It supports three-phase motors up to 40 hp at 208 V, 50 hp at 240 V, and 100 hp at 480/600 V. The starter includes a C306 bi-metal overload relay with adjustable heater packs (sold separately) and operates with coil voltages of 110 V at 50 Hz or 120 V at 60 Hz. It is UL listed and CSA certified, built to standard NEMA construction for reliable performance.

• Manufacturer: Cutler Hammer (Eaton)
• Amperage Rating: 135 A
• Voltage: 600 V max
• Poles: 3
• Phase: Three-phase
• Mounting Type: Horizontal surface mount
• Enclosure: NEMA Size 4 open type
• Overload Relay: C306 bi-metal, Class 10/20
• Coil Voltage: 110 V (50 Hz) / 120 V (60 Hz)
• Configuration: Full voltage non-reversing
• Horsepower Ratings: 40 hp @ 208 V, 50 hp @ 240 V, 100 hp @ 480/600 V
• Certifications: UL Listed, CSA Certified

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: AN16NN0A
• Manufacturer : Cutler Hammer
• Brand : Cutler Hammer
• Category : Motor Control
• Item Subcategory : Motor Starter
• Family : Freedom Series
• Type : AN16
• Voltage : 600
• Amperage : 135
• Phase : 3
• Poles : 3
• Coil Voltage Maximum : 120
• Coil Voltage Minimum : 110
• Nema Rating : 4

Product Data

• UPC : 078211360411
• GTIN : 7.82114E+11
• Country of Origin : Dominican Republic
• Dimensions : 6.75 in x 4.63 in x 6.63 in (Length/Depth x Height x Width)
• Weight : 9.3 lb
• Certification : CSA Certified,UL Listed
