Product Info
- Manufacturer:Mersen
- Sub-Category:Low Voltage Fuse
Description
A4BY5000-55BA
A4BY5000-55BA is a Class L time-delay fuse designed for high-amperage distribution applications, providing reliable protection for service entrance equipment, feeders, and circuit breakers. This fuse features a blade-style mounting and is rated for continuous operation up to its full ampere rating, with a 4-second minimum time delay at 500% of rated current to accommodate normal surges and coordinate with ground fault relays. The A4BY5000-55BA offers current-limiting performance and is constructed with a glass melamine body and plated terminals for durability in harsh environments. Its unique dimensions prevent replacement by other fuse classes, ensuring correct installation and system safety. The fuse is suitable for mains, feeders, load centers, panelboards, switchboards, and metering centers.
- Amperage: 5000 A
- Voltage AC: 600 V
- Voltage DC: 300 V
- Mounting Type: Blade
- Interrupt Rating: 5 kA
- Fuse Class: Class L
- Speed/Characteristic: Time Delay
- Series: A4BY
- UL Category Code: JDDZ
- UL File Number: E2137
- CSA File Number: Class 1422-02 Guide 012636_0
- Compliance: RoHS, REACH
Specifications
- Part Number: A4BY5000-55BA
- Manufacturer : Mersen
- Brand : Ferraz Shawmut
- Category : Fuse
- Item Subcategory : Low Voltage Fuse
- Family : Amp-Trap
- Type : A4BY
- Voltage : 600
- Amperage : 5000
Product Data
- UPC : 782001938574
- GTIN : 00782001938574
- Weight : 0.15
