A25RES25T1 - Eaton 2500A Circuit Breaker Rating Plug Series G Frame J-K

A25RES25T1

A25RES25T1 is an Eaton circuit breaker rating plug designed for adjustable amperage settings up to 2500A in Series G frame breakers.

This rating plug is compatible with Eaton Series G RD, RDC, CRD, CRDC, RGH, RGC, RW, and RWC frame circuit breakers, providing adjustable current ratings of 1200, 1600, 2000, and 2500 amps. It supports a voltage rating of 600VAC and is used with electronic trip units featuring interchangeable rating plugs, such as the Digitrip RMS 310. The compact design ensures easy installation and reliable performance in power distribution applications.

Key Specifications
• Manufacturer: Eaton
• Part Number: A25RES25T1
• Amperage Rating: Adjustable 1200, 1600, 2000, 2500A
• Voltage Rating: 600VAC
• Compatible Series: Series G
• Frame Type: J-K Frame
• Trip Unit Compatibility: Electronic (Digitrip RMS 310)
• Mounting Type: Rating Plug
• Product Width: 1.8 inches
• Product Weight: 0.05 lb
• Warranty: 1 year from installation or 18 months from shipment

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: A25RES25T1
• Manufacturer : Eaton
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Rating Plug
• Family : Series G
• Type : A25RES
• Amperage : 2500
• Frame Size : 2500
• Amperage Maximum : 2500
• Amperage Minimum : 1200
• Compatible Frames : RD,RDC,CRD,CRDC,RGH,RGC,RW,RWC
• Trip Type : DIGITRIP,RMS310,RES

Product Data

• UPC : 786679582107
• GTIN : 00786679582107
• Country of Origin : United States
• Dimensions : 5 in x 1.5 in x 1.8 in (Length/Depth x Height x Width)
• Weight : 0.05
• Certification : Ul Listed Csa Certified
