A20RES20T1 - Cutler Hammer 2000A 600V Adjustable Rating Plug for Series G Circuit Breakers

A20RES20T1

A20RES20T1 is a Cutler Hammer adjustable rating plug designed for Series G circuit breakers with a maximum current rating of 2000A and voltage rating of 600VAC.This rating plug is compatible with Frame J-K breakers and supports adjustable amperage settings of 1000, 1200, 1600, and 2000 amps. It features an electronic Digitrip RMS 310 trip unit and is intended for use with R-frame style breakers. The plug provides precise breaker current rating adjustment to optimize protection and coordination.

• Manufacturer: Cutler Hammer (Eaton)
• Part Number: A20RES20T1
• Amperage Rating: Adjustable 1000-2000A
• Voltage Rating: 600VAC
• Frame Size: J-K
• Trip Unit: Electronic Digitrip RMS 310
• Type: Adjustable Rating Plug
• Compatible Series: Series G (RD, RDC, CRD, CRDC, RGH, RGC, RW, RWC)
• Mounting Type: Plug-in for circuit breaker
• Interrupt Rating: Matches breaker frame rating
• Certifications: Manufacturer standard certifications apply

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: A20RES20T1
• Manufacturer : Cutler Hammer
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Rating Plug
• Family : Series G
• Type : A20RES
• Amperage : 2000
• Frame Size : 2000
• Amperage Maximum : 2000
• Amperage Minimum : 1000
• Compatible Frames : RD,RDC,CRD,CRDC,RGH,RGC,RW,RWC
• Trip Type : DIGITRIP,RMS310,RES

Product Data

• UPC : 786679582008
• GTIN : 00786679582008
• Country of Origin : United States
• Dimensions : 5 in x 1.6 in x 1.7 in (Length/Depth x Height x Width)
• Weight : 0.1
