60159 - Schneider Electric Multi9 C60 2P 7A 120/240V Circuit Breaker

60159

60159 is a Schneider Electric Multi9 C60 miniature circuit breaker designed for single-phase power distribution and branch circuit protection in residential and light commercial applications.

This molded case circuit breaker features a C-curve trip characteristic with thermal-magnetic protection, providing reliable overcurrent and short-circuit protection. The unit is rated for 120/240V AC operation with a 10kA interrupt capacity at 240V, making it suitable for standard North American electrical systems. The breaker includes feed-thru terminals for flexible installation configurations and is certified by CSA and UL to UL1077 standards.

• Part Number: 60159
• Manufacturer: Schneider Electric
• Series: Multi9 C60
• Poles: 2-Pole (2P)
• Amperage: 7A
• Voltage: 120/240V AC
• Interrupt Rating: 10kA @ 240V
• Trip Curve: C-Curve (Thermal-Magnetic)
• Certifications: CSA, UL1077
• Configuration: Feed-Thru Terminals

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: 60159
• Manufacturer : Schneider Electric
• Brand : Schneider Electric
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Multi9
• Type : C60
• Voltage : 240
• Amperage : 7
• Phase : 1
• Poles : 2
• AIC rating : 10kA@240V
• Connection : Feed-Thru
• Functions : LI - Long-Time and Instantaneous
• Protection : Thermal Magnetic

Product Data

• UPC : 786210601595
• Dimensions : Height 4.21 in (107 mm) x Depth 3.09 in (78.49 mm) x Width 4.44 in (112.78 mm)
• Weight : 1
• Certification : UL E9809
