Description
45GG20AH
45GG20AH is a Siemens Class 45 definite purpose contactor designed for reliable motor control applications. This 2 pole, 40A contactor features a 480V AC coil and is rated for up to 600VAC switching voltage, making it suitable for a wide range of industrial uses. Engineered for durability and performance, the 45GG20AH contactor includes auxiliary contacts and screw terminal connections. It operates at 50/60 Hz frequency and is built to withstand demanding environments with a maximum operating temperature of 70°C. The compact design allows for easy mounting in control panels and enclosures.
- Part Number: 45GG20AH
- Manufacturer: Siemens
- Series/Frame: Class 45
- Poles: 2
- Amperage: 40A
- Switching Voltage: 600VAC
- Coil Voltage: 480V AC
- Mounting Type: Screw Terminal
- Interrupt Rating: Not specified
- Features: Auxiliary Contacts
- Operating Temperature: 70°C
- Frequency: 50/60 Hz
Specifications
- Part Number: 45GG20AH
- Manufacturer : Siemens
- Brand : Siemens
- Category : Motor Control
- Item Subcategory : Contactor
- Family : Class 45
- Type : 45GG
- Voltage : 600
- Amperage : 40
- Phase : 1
- Poles : 2
- Temp Rating : -13–158 °F (-25–70 °C)
- Coil Voltage Maximum : 480
- Full Load Amps : Full Load Amps-Inductive 40A Full Load Amps-Resistive
Product Data
- UPC : 783087208209
- GTIN : 00783087208209
- Country of Origin : China
- Dimensions : 3.937 x 2.756 x 2.362 inch
- Weight : 0.617
- Temp Rating : -13–158 °F (-25–70 °C)
- Certification : REACH Art 33
