Description
45GG20AF
45GG20AF is a Furnas Class 45 definite purpose contactor designed for reliable motor control applications. This 2-pole device features a 120VAC coil and is rated for 40A at 600V, making it suitable for a wide range of industrial uses. The contactor is built with an open enclosure and silver cadmium oxide contacts for durability and consistent performance. It is commonly used in HVAC, refrigeration, and other motor-driven systems. The 45GG20AF contactor is part of the Furnas Class 45 series, known for its robust construction and compatibility with standard mounting configurations. It supports both single and multi-stranded conductors up to 4 AWG and features quick-connect coil terminals and screw-type auxiliary contacts for easy installation and maintenance. The device is certified to cRUus, UL, and ARI standards, ensuring compliance with industry safety requirements.
- Part Number: 45GG20AF
- Manufacturer: Furnas
- Series/Frame: Class 45
- Amperage: 40A
- Voltage: 600VAC
- Poles: 2
- Coil Voltage: 120VAC
- Mounting Type: Standard DIN rail or panel mount
- Enclosure Type: Open
- Contact Material: Silver Cadmium Oxide
- Conductor Size: 4 AWG
- Certifications: cRUus, UL, ARI
Specifications
- Part Number: 45GG20AF
- Manufacturer : Furnas
- Brand : Furnas
- Category : Motor Control
- Item Subcategory : Contactor
- Family : Class 45
- Type : 45GG
- Voltage : 600
- Amperage : 40
- Phase : 1
- Poles : 2
- Coil Voltage Maximum : 120
Product Data
- UPC : 783087158252
- GTIN : 00783087158252
- Country of Origin : China
- Dimensions : 3.543 x 3.15 x 2.362 inch
- Weight : 0.617
